BULLDOZER

Engine power: TY395(30hp) Clutch:hydraulic reverse shuttle clutch Gear box:8F+8Rev. Brakes & Steering:Steering paddles integrated with the Brake Paddles Steering Clutch:Multiple powder metallurgy disc dry Clutch Brakes:Band Brakes,paddles control Power take off:mechanical dependent 540/1000rpm/35mm/6splines Undercarriage rollers:Semi-rigid-off Track Frame Track rollers:5+1(each side) Track recoil system:Hlical spring,Screw Adjusted Width of Track Shoes:300 Hydraulic system:Blade & Hitch Capacity at governed rpm:25.2Lpm Relief Valve Pressure:16 Mpa Blade capacity:0.67 Lifting capacity at hitch point:7350N Weight & Dimension: L*W*H:2960*1450*2285mm(with blade) Ground clearance:240-245mm Operating weight:2830kg Max Drawbar pull:2350kg 4 in 1 front loader index: Rated loading capacity 550kg Volume of the backet 0.3m3 Bucket dump height:2200mm Dumping distance:550mm Bucket lifting angle:45 degree Bucket tilt angle:48 degree Bucket deep:100 mm Working pressure:16 Mpa Loader Lifting time:7s Loader descend time:less than 4s
